10/100Base-TX MDI/MDIX Ports

24

Throughput (packet per second)

3.57Mpps

Switch Fabric

4.8Gbps

Weight

1.7kg

Power Consumption / Dissipation

4 watts / 13 BTU

Power Requirements

100~240V AC, 50/60Hz, 0.3A

Dimensions (W x D x H)

440 x 180 x 44mm, 1U height

Switch Processing Scheme

Store-and-Forward

Address Table

8K entries

Packet Buffer

2Mbit SRAM

Power Green Ethernet

10m ~ 50m: Saving up to 12%

Flow Control

Back pressure for half duplex, IEEE 802.3x pause frame for full duplex

Temperature

Operating: 0~50 degrees C
Storage: -10~70 degrees C

Humidity

Operating: 5% to 95%,
Storage: 5% to 95% (Non-condensing)
