Image Sensor:

1/2.7” CMOS Sensor

Min. Illumination:

0.1 Lux / F1.8, 0 Lux (IR LED ON)

Shutter time:

1/30 (1/25) sec ~ 1/720000 (1/600000) sec

Lens:

3.6mm

Lens Angle:

96° (Horizontal) / 50° (Vertical) / 116° (Diagonal)

Day& Night Mode:

Yes

IR LED:

12 units

AGC:

Adjustable

Backlight Compensation:

Adjustable

Video Frame Rate:

1080P@30fps / 1080P@25fps

Operating Conditions:

-20 °C ~ 40 °C

Power Supply:

12 VDC

Power Consumption:

250mA

Weather Proof Ratings:

IP66

IR Range:

Up to 15m

Dimensions:

Φ185.50mm × 162.54 × 66.42

lens

3.6mm

leds

IR LEDs (up to 15m)

Push video

NO

Resolution

1080P

Mega Pixel

No

Onvif

No

PoE

No

Night vision

Yes
