IPC3612SR3-PF28

IPC3612SR3-PF36

IPC3612SR3-PF60

Camera

Sensor

1/3", 2megapixel, progressive scan, CMOS

Lens

2.8mm@F1.8

3.6mm@F1.8

6mm@F1.8

Angle of view(H)

88.9°

65.7°

41.5°

Shutter

Auto/Manual, 1/6~1/100000 s

Min. Illumination

Colour: 0.06 Lux (F1.8, AGC ON)

0 Lux with IR

IR

30m (98ft) IR range

Day/Night

IR-cut filter with auto switch (ICR)

WDR

Supported

AWB(Auto white balance)

Auto/manual

Gain Control

Auto/manual

Noise Reduction

2D/3D

Video

Max. Resolution

1920×1080

Video Compression

H.264/MJPEG

Frame Rate

1080P (1920×1080): Max. 30 fps; 720P (1280×720): Max. 30 fps;D1 (720×576): Max. 25 fps

Video Streaming

Triple

9:16 Corridor Mode

Supported

OSD

Up to 8 OSDs

Motion Detection

Up to 2 areas

Privacy Mask

Up to 4 areas

Network

Protocols

IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,RTP,RTSP,Qos,DNS,DDNS,NTP,FTP,UPnP,HTTP

Compatible Integration

ONVIF, API

Interface

Network

10M/100M Base-TX Ethernet

General

Power

12 V DC, or PoE (IEEE802.3 af)

Power consumption: 3.5 W (5.5W with IR on)

Dimensions (Ø x H)

Φ126 x 94 mm (Ø5.0” x 3.7”)

Weight

0.33 kg (0.73lb)

Working Environment

-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)

Ingress Protection

IP66
