IPC2122SR3-PF36

IPC2122SR3-PF60

IPC2122SR3-PF120

Camera

Sensor

1/2.8", 2.0 megapixel, progressive scan, CMOS

Lens

3.6mm@F1.8

6.0mm@F1.8

12.0mm@F1.8

Angle of View(H)

79.7°

51.6°

26.3°

Shutter

Auto/Manual, 1/6~1/8000 s

Min. Illumination

Colour: 0.02 Lux (F1.8, AGC ON)

0 Lux with IR on

IR Range

Up to 30m (98 ft) IR range

Day/Night

IR-cut filter with auto switch (ICR)

S/N

>52dB

WDR

Digital

Noise Reduction

2D/3D

Video

Max. Resolution

1920×1080

Video Compression

H.264/MJPEG

Frame Rate

1080P (1920*1080): Max. 30 fps; 720P (1280*720): Max. 30 fps; D1 (720*576): Max. 25 fps

Video Streaming

Triple

9:16 Corridor Mode

Supported

ROI

Supported

OSD

Up to 8 OSDs

Motion Detection

Up to 2 areas

Privacy Mask

Up to 4 areas

Network

Protocols

L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SNMP, SIP, QoS

Compatible Integration

ONVIF, API

Interface

Network

1 RJ45 10M/100M Base-TX Ethernet

General

Power

12 V DC, or PoE (IEEE802.3 af)

Power consumption: Max 6.4 W

Dimensions (L × W × H)

157.3 × 62.4 ×63 mm (6.2” × 2.5” × 2.5”)

Weight

0.45 kg (0.99 lb)

Working Environment

-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 95% RH(non-condensing)

Ingress Protection

IP66
