IPC262ER9-DUZ

IPC262ER9-X10DU

Camera

Sensor

1/2.8", 2 megapixel, progressive scan CMOS

Lens

2.8~12mm@F1.6; P-Iris

4.7 ~ 47mm@F1.6; P-Iris

Angle of View (H)

97°(wide)~ 35°(tele)

65°(wide) ~ 9°(tele)

Zoom/Focus

4X Optical Zoom / Auto Focus

10X Optical Zoom / Auto Focus

Shutter

Auto/Manual, 1/10~1/100,000s

Min. Illumination

Colour: 0.002 Lux (F1.6, AGC ON)

0 Lux with IR

IR Range

Smart-IR ,up to 100m (328ft) IR range

Day/Night

IR-cut filter with auto switch (ICR)

S/N

>52dB

WDR

120dB

Video

Max. Resolution

1920× 1080

Video Compression

H.265, H.264, MJPEG

Frame Rate

1080P (1920*1080): Max. 30 fps

Video Streaming

Triple

9:16 Corridor Mode

Supported

ROI

Supported

OSD

Up to 8 OSDs

Privacy Mask

Up to 8 areas

Smart

Behavior Detection

Intrusion, crossing line, motion detection

Exception Detection

Audio detection

Intelligent Identification

Face detection

Statistical Analysis

People counting

Audio

Audio Compression

G.711

Two-way audio

Supported

Storage

Edge Storage

Micro SD, Up to 128 GB

Network

Protocols

L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x

Compatible Integration

ONVIF, API

Interface

Audio I/O

Audio cable

1 Input: impedance 35 kΩ; amplitude 2 V [p-p]

1 Output: impedance 600 Ω; amplitude 2 V [p-p]

Alarm I/O

2 / 1

Serial Port

1 RS485

Network

10M/100M Base-TX Ethernet

Video Output

1 BNC, impedance 75 Ω; amplitude 1 V [p-p]

General

Power

DC12V±25%, AC24V±25% or PoE (IEEE802.3 at)

Power consumption: 13.7W

Dimensions (L × W × H)

305.5 ×104.1 ×97.3mm (12.0” × 4.1” × 3.8”)

Material

Cast aluminum

Weight

1.65 kg (3.6 lb)

Working Environment

-40°C ~ +60°C (-40°F ~ 140°F), Humidity ≤ 95% RH(non-condensing)

Ingress Protection

IP67
